¢ Model: AOYG18KATA
Operation mode Outdoor temp. (Ta) Trigger condition Release condition
Cooling
50°C ≤ Ta 4.0 A 3.5 A
46°C ≤ Ta < 50°C 4.5 A 4.0 A
40°C ≤ Ta < 46°C 6.0 A 5.5 A
12°C ≤ Ta < 40°C 8.5 A 8.0 A
2°C ≤ Ta < 12°C 8.5 A 8.0 A
Ta < 2°C 8.5 A 8.0 A
Heating
17°C ≤ Ta 7.0 A 6.5 A
12°C ≤ Ta < 17°C 8.5 A 8.0 A
5°C ≤ Ta < 12°C 8.5 A 8.0 A
Ta < 5°C 8.5 A 8.0 A
¢ Model: AOYG22KATA
Operation mode Outdoor temp. (Ta) Trigger condition Release condition
Cooling
50°C ≤ Ta 4.5 A 4.0 A
46°C ≤ Ta < 50°C 4.5 A 4.0 A
40°C ≤ Ta < 46°C 6.0 A 5.5 A
12°C ≤ Ta < 40°C 10.0 A 9.5 A
2°C ≤ Ta < 12°C 10.0 A 9.5 A
Ta < 2°C 10.0 A 9.5 A
Heating
17°C ≤ Ta 7.0 A 6.5 A
12°C ≤ Ta < 17°C 9.0 A 8.5 A
5°C ≤ Ta < 12°C 10.0 A 9.5 A
Ta < 5°C 10.0 A 9.5 A
8-4. Indoor unit fan motor over temperature protection
When satisfy the following conditions, the protection works.
• After the 90 seconds from the fan operation, detect less than 300 rpm for 10 seconds.
• IPM trip protection works.
• Current overload protection works.
When detecting the above condtion, recheck the condition after 6 minutes. When count the twice,
the protection works.
• Protection contents
Reduce the static pressure 20 Pa. When it does not dissolve even the minimum static pressure
condition, work the following operation.
– Fan motor error displayed when less than 300 rpm for 10 seconds is detected after the 90 sec-
onds from the fan operation.
– Fan stop 40 seconds when IPM trip protection works.
– Fan stop 50 seconds when corrent overload protection works.
8-3. Current release control
- (04-35) - 8. Various protections
