Model: UTP-SX354A
Unit: mm
Port diameters
Liquid pipe Q’ty Gas pipe Q’ty
Ø6.35 Ø6.35 Ø6.35
Ø9.52
Ø12.70
1
Ø12.70
Ø15.88
Ø19.05
Ø12.70
Ø12.70
1
Dimensions
Liquid pipe Gas pipe
53
15
15
175
70 70
300
53
15
15
130
140 70 70
Heat insulation cover
Liquid pipe Q’ty Gas pipe Q’ty
1 1
Others
Cable tie Q’ty
1
