When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
4 Emblem-Rear 93598360189359836018
5 Cabinet-A, Painted 9359797029 9359797029
6 Cabinet-C, Painted 9363798029 9363798029
9 Cabinet-B 9363797022 9363797022
12 Base Assy, Painted 9364145020 9364145020
13-1 3-Way Valve Assy 9372205075 9372205075
16 Condenser Assy 9373254010 9373254010
26-2 Compressor Cover-B 9372067017 9372067017
26-3 Compressor Cover-C 9370186000 9370186000
29 Separate Wall-B 9369625015 9369625015
32-7 Control Box Metal-G 9369616006 9369616006
32-8 Control Box Metal-H 9369617003 9369617003
32-9 Control Box Metal-I 9369618000 9369618000
32-10 Control Box Metal-J 9369619007 9369619007
45-1 Motor Bracket-A 9369627002 9369627002
45-2 Motor Bracket-B
9369628009 9369628009
45-4 Motor Bracket-D
9369630002 9369630002
46 Compressor Assy 9373531012 9373531012
64 Cabinet Left. 9359840022 9359840022
629 Coil, Choke 9703458019 9703458019
764 Drain Cap 313166024302 313166024302
734 Cabinet Top Plate 9359799023 9359799023
Ref.
No.
Description
Ord.
Q'ty
Part No.
Ref.
No.
Description
Ord.
Q'ty
Part No.
AOY30LMALAOY24LMAL
AOY30LMALAOY24LMAL
84 Valve Cover 9363802009 9363802009
69-3 Bolt, Hex.Socket 301210060360 301210060360
107 Rubber Seat-A 9358080009 9358080009
109 Terminal Cover 9370289008 9370289008
117-3 Hex. Nut w/SP. Washer 301721180114 301721180114
138 2-Way Valve Assy 9372204061 9372204061
176 Valve Fixing Plate-A 9363799064 9363799064
181 ACTPM 9703457012 9703457012
183-1 Water Seal Plate-B 9369626012 9369626012
185-2 Rubber Washer 9358078006 9358078006
203 TR PCB Assy 9704009029 9704009029
204 Heat Sink-B 9369793004 9369793004
788 Thermistor (Disc Temp. ) 9704219077 9704219077
815 Terminal-6P 9358660089 9358660089
824 Fuse 06000860390600086039
824-3 Fuse 0600222512 0600222512
824-4 Fuse 0600222529 0600222529
825-1 EXP Valve Assy 9373251019 9373251019
875 Filter PCB Assy 9704722010 9704722010
886 Heat Sink-A 9369792007 9369792007
887-1 Reactor Cover 9369622007 9369622007
910 Strainer-B 9365099018 9365099018
949-1 Screw , Painted 9305648009 9305648009
950 Accum Support Sheet 9354022010 9354022010
e Seperate Wall Ins B 9360074201 9360074201
823 Fuse Holder 0500158072 0500158072
951 Accum SPT AS 313986353804 313986353804
953 Motor Bracket CTR 9373076018 9373076018
952 Acum HLD Rub 9354022010 9354022010
967 Comp Temp Thermo. 9900156015 9900156015
549 PTC Thermistor 9704265012 9704265012
381-3 Locking Spacer 0600118051 0600118051
408 Special Nut M8 9355091008 9355091008
411 Holder 9372066010 9372066010
412 Terminal Packing 9370290004 9370290004
477 Bell-Mouth 9359809012 9359809012
527 Protectine Net 9359844013 9359844013
OUTDOOR UNIT
242004.09.15
32-11 Control Box-K 9369620010 9369620010
34 Capacitor (Fan Motor) 9704305015
39 Propeller Fan 9359837015 9359837015
40 Air seal Plate 9369623004 9369623004
9704305015
41 Fan Motor Assy Out 9601754015 9601754015
3 Fan Guard 9371187013 9371187013
7 Noise Ins A 9370181005 9370181005
47 Comp Plate Assy 9363800005 9363800005
186 Frange nut 9358079003 9358079003
235 Thermo.(Heat Exchi) 9704220059 9704220059
236 Controller PCB Assy 9704719072 9704719089
(EZ-003PHUE-C) (EZ-003RHUE-C)
255 Insulation ( Heat Sink ) 9370844009 9370844009
333 Accumulator 9351997014 9351997014
343 Solenoid 9900165024 9900165024
343-1 Coil (EXP Valve) 9970006012 9970006012
344 4-way Valve 9900163013 9900163013
373 Grip 9352157004 9352157004
381-2 Locking Spacer 0600035020 0600035020
353 Thermistor Assy-Out 9703516054 9703516054
Capacitor---- 9704729019 9704729019
To Next Page
