PARTS LIST
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
Ref.
No.
Description
AWY24LBAJ
Ord.
Q'ty
8-2 Filter Frame 9367681013 9367681013
12 Base-B 9368216016 9368216016
32 Control Box 9367663002 9367663002
45 Bracket (Eva. ) Assy 9369317019 9369317019
62 Fan Motor-Inner 9601385028 9601385028
63 KIT (Front Cover) 9371132099 9371132099
63-1 Service Cover Assy 9368837013 9368837013
67 Rubber (Motor) 9367676002 9367676002
69 Louver 9367706013 9367706013
70-1 Hook (Cover)-L 9367675012 9367675012
70-2 Hook (Cover)-R 9367674015 9367674015
92 Link Arm 9367694006 9367694006
93 Filter 9367680016 9367680016
108-1 Base Assy 9368829056 9368829049
108 Base 9367683017 9367683017
108-2 Base-B Sub Assy 9368843014 9368843014
109 Terminal CVR 9368022006 9368022006
120 Eva. Sub Assy 9368832070 9368832056
122 Rub (Bearing) Assy 9368998004 9368998004
127 Drain Hose 9367695003 9367695003
146 Evaporator Assy 9371999012 9371999012
146-1 Evaporator Assy-B 9369124006 9369124006
158 Joint Pipe Assy 9369144004 9369144004
160 Drain Pan Assy 9368835026 9368835019
165 Motor Box 9367718009 9367718009
169 Cross Fan Assy 9367708000 9367708000
172 Pipe Bracket 9367844005 9367844005
172-3 KIT (Pipe Holder) 9371135014 9371135014
174-1 Fixing Plate 9367987009 9367987009
184-1 Thermo. Spring-A 313728262708 313728262708
199 Step Motor 9900020019 9900020019
230 Diffusion Sheet 9368006013 9368006013
234 Thermistor Assy-Room 9703299148 9703299148
235 Thermistor Assy-Pipe 9703297038 9703297038
236 Controller PCB Assy 9705066021 9705066014
240 Remote Control Unit 9371190112 9371190112
253-1 Wire With Connector 9704434012 9704434012
253-2 Wire With Connector 9704435019 9704435019
253-3 Wire With Connector 9704433015 9704433015
320 Upper Flap 9367688012 9367688012
Part No.
AWY30LBAJ
Ref.
No.
Description
AWY24LBAJ
Ord.
Q'ty
Part No.
AWY30LBAJ
629 EMI Filter 0400056133 0400056133
735 Distributor Assy 9370560008 9370560008
743 Remote Control Holder 9305642014 9305642014
759-1 Intake Cover 9367678013 9367678013
764 Drain Cap 9367677009 9367677009
815-1 Terminal-3P 9306489090 9306489090
855 Display-F 9367672011 9367672011
868 PWB Holder (Display) 9371131016 9371131016
875 PCB Assy-Switch 9704370013 9704370013
945 Wire Holder 9368016005 9368016005
960 Diffuser Assy 9368840013 9368840013
963 Fan Guard 9368015008 9368015008
963-1 Fan Guard Holder 9367707003 9367707003
973 Gear Box 9367690008 9367690008
998 Bypass Pipe-B Assy 9372000014 9372000014
999 Bypass Pipe 9369126000 9369126000
329 Coupling Pipe Assy 9370561005 9370561005
338 Motor Holder 9367798001 9367798001
345 KIT (FILTER GUIDE) 9371130019 9371130019
385 Indicator PCB Assy 9704368010 9704368010
407 Motor Link 9367696000 9367696000
407-2 Louver Rod 9367698004 9367698004
408 Louver Link 9367697007 9367697007
408-1 Louver Link-B 9368789008 9368789008
425 Earth Plate 9368017002 9368017002
428 Screw Cover 9367717019 9367717019
435 Louver Spring 9369030000 9369030000
514 Control Box Cover 9367664009 9367664009
522-1 Gear-A 9367691005 9367691005
522-2 Gear-B 9367692002 9367692002
557 Spring (Diffuser) 9368824006 9368824006
574-1 Eva. Support-R 9367684007 9367684007
574-2 KIT (Eva. Support-L) 9371129013 9371129013
588 Eva. Holder 9367711000 9367711000
588-1 Eva. Holder-B 9368783006 9368783006
627 Link 9367693009 9367693009
232004.07.22
321 Lower Flap 9367689019 9367689019
