4 - English Interfaces and connecto r
s
Interfaces and connectors
The location of the interfaces and connectors of your mainboard is specified
at the b eginning of the manual.
The c omponents and con nectors marked are not necessarily present on the mainboard.
External p orts
The location of the external connections of your mainboard is specified at the beginning of the manual.
PS/2 keyboard port, purple PS/2 mouse port, green
LAN port (RJ-45) Microphone jack (mono), pink
Audio input (line in), light blue or black USB – Universal Serial Bus, black
Audio output (line out), light green or
black
DVI – I
Serial interfa ce, t urquoise
+
+
DisplayPort
According to the USB 2.0 speci fications, no more than 500 mA must
be connected to the external USB ports.
The use of a new chip set technology can mean that the p rocedure is different when
connecting older USB devices (Fullspeed, USB 1.1). This relates, for example, to older
digital cameras of which only on e (not two or more at the same time) can be operated at
any one time. Newer devices with specification USB 2.0 are n ot affected by this.
20 Fujitsu Technology Solutions
