Fujitsu D3171 - Internal Connectors and Slots; External Connectors (Rear View); Front Panel Connectors

Internal connectors and slots
External connectors rear
USB 2.0
1
2
1 = 5V USB
2 = 5V USB
3 = Data negative Port X
4 = Data negative Port Y
6 = Data positive Port Y
Data positive Port X
7 =
5 =
GND
8 = GND
9 = Key
10 = Not connected
A26361-D3171-Z320-1-7419
Module 2 Channel B
Module 4 Channel B
Module 1 Channel A
Module 3 Channel A
Battery
HD-Audio
PS2
DVI-D
COM1
VGA
USB Port
9+12+12+13
PCIe1
PCIe1
PCI
PCIe16
FAN1
FAN2
Frontpanel
LAN
SATA 0+1
SATA Power
USB
USB
PCH
CPU
LGA1155
Parallel Port
SATA 4+5
Audio Frontpanel
LAN
USB 3.0
Port 0+1
Power Supply
Tempsensor
Tempsensor
DVI-D
Front panel
1
2
HD-LED
Recovery
Reset
Power
On/Off
Power LED
Recovery inserted = The system starts
from USB stick and allows a BIOS
recovery. Details can be found in the
BIOS manual.
Buzzer
TPM
Audio
Desc Override Enable
Port 8+10
Port 4+5
USB 3.0
1 = 5V USB
2 = USB3_RX negative (P2)
3 = USB3_RX positive (P2)
4 = GND
USB3_TX negative (P2)
5 =
19
1
6 = USB3_TX positive (P2)
7 = GND
8 = Data negative (P2)
9 = Data positive (P2)
10 = FP Detect
USB 3.0
Port 2+3
11 = Data positive (P3)
12 =
Data negative (P3)
13 = GND
14 = USB3_TX positive (P3)
USB3_TX negative (P3)
15 =
16 = GND
17 = USB3_RX positive (P3)
18 = USB3_RX negative (P3)
19 = 5V USB
20 = Not connected
