Fujitsu D3607 - Overview

Overview
2 Fujitsu
Overview
The D3607 is a complete low profile PCI Express Gigabit Ethernet Adapter (in the following text
called NIC) utilizing the BCM57762 LAN Controller.
The NIC is available with ATX I/O connector bracket and/or low profile bracket.
LAN Controller Broadcom BCM57762
LAN interface 10/100/1000 Base-T - IEEE 802.3 compliant
Host interface x1 PCIexpress 1.1 bus interface
Performance 40 Kbyte receive and 22 KByte transmit buffer
TCP, IP, and UDP checksum Offload
Microsoft® Large Send Offload
Receive Side Scaling (RSS)
Manageability ACPI
Wake on LAN by interesting packets and Magic-Packet
TM
Special feature PXE support
Memory for LAN
Controller
2 MBit FLASH
Connector RJ45 connector
Driver Support Windows® 7
Windows® 8.1
Windows® 10
Linux
Form factor PCI Express low profile Card 66.0 x 62.5 mm
