5. Connecting with optional remote sensor
Remote sensor cables
Indoor unit
(accessory)
Cable tie (small)
CN8 (black)
CN7 (white)
sensor
Remote
(accessory)
Cable tie (small)
(accessory)
Cable tie (small)
sensor
Remote
DESIGN & TECHNICAL MANUAL
- 48 -
ZONE CTRL SYSTEM
with WLAN ADAPTER
