Fujitsu General ARHG30LMLE

12 Cabinet L Sub Assy
11 Cabinet R Sub Assy
13 Outlet Panel Sub Assy
15 Evaporator Sub Assy
14 Drain Pan Sub Assy
Ref. Description
2013.02.07 16
INDOOR UNIT
Part number
9374509010
9374508020
9374510016
9374517312
9374513017
11
15
13
12
14
21
19
18
20
18 Main PCB (30)
18 Main PCB (36)
9709245217
21 Terminal 3P 9703345012
22 Terminal 3P 9306489045
19 Power Supply PCB 9707398359
20 Reactor Assy 9707457018
Room Thermistor 9703299025--
Pipe Thermistor 9703297021--
9709245224
22
16
17 Sirocco Fan Assy
16 Base Sub Assy
9356531046
9374504015
17
