ACCESSORIES
INDOOR UNIT
Name and Shape
Hanger
Special nut A
(large flange)
Special nut B
(small flange)
Coupler heat
insulation (large)
Coupler heat
insulation (small)
Q'ty
4
4
4
1
1
Application
For suspending the indoor
unit from ceiling
For suspending the indoor
unit from ceiling
For indoor side pipe joint
(large pipe)
For indoor side pipe joint
(small pipe)
Binder
Drain hose insulation
1
(large)
1
(small)
1
For fixing the drain hose
For fixing the remote
controller cord
Insulates the drain hose
and vinyl hose
2013.02.27 21
Name and Shape
Q'ty Part numberApplication
1
2
OUTDOOR UNIT
For drain piping work
Drain pipe
Drain cap
9303029015
313166024302
Remote
control
1
For air conditioner
operation
Remote control cord
(*1)
1
For connecting the
remote control
Tapping screw
(ø4 × 16)
2
For installing the
remote control
