Fujitsu General ARHG30LMLE

9
5
2
4
1
3
INDOOR UNIT
PARTS
2013.02.06 15
9 Control Cover A Sub Assy
2 Intake Cover Sub Assy
3 Main Panel Sub Assy
4 Intake Frame Assy
Ref. Description Part number
9374516025
9374512010
5 Bracket Pipe Sub Assy 9374514014
9374511013
9374216017
1 Remote Control 9318593013
7
8
8 Fan Motor
7 Casing B
6 Casing A
9374234028
9374233021
9603213015
