91
Wireless LAN User’s Guide
WLAN Specifications
SPECIFICATIONS
* “Wi-Fi based” indicates that the interconnectivity test of the organization which guarantees the interconnectivity of
wireless LAN (Wi-Fi Alliance) has been passed.
** The communication ranges shown above will increase or decrease depending on factors such as number of walls,
reflective material, or interference from external RF sources.
*** Encryption with network key (WEP) is performed using the above number of bits, however, users can set 40 bits/
104 bits after subtracting the fixed length of 24 bits.
**** Depending on practical environments, the allowable number of computers to be connected may be decreased.
Item Specification
Type of network The Intel PRO/Wireless 3945ABG Network Connections WLAN
and
Atheros AR5006EXS (AR5BXB6) Mini-PCI wireless
network card (802.11a+b/g) devices conform to IEEE 802.11a
and 802.11b/g (Wi-Fi based)*.
Transfer rate (Automatic switching) 54 Mbps maximum data rate
Active frequency 802.11b/g: 2400~2473 MHz
802.11a: 4900 ~ 5850 MHz
Number of channels 802.11a: 8 independent channels
802.11b/g: 11 channels, 3 non-overlapping channels
Typical operating distances** 802.11a: 40 ft. (12 m) @ 54 Mbps; 300 ft. (91 m) @ 6 Mbps
802.11b: 100 ft. (30 m) @ 11 Mbps; 300 ft. (91 m) @ 1 Mbps
802.11g: 100 ft. (30 m) @ 54 Mbps; 300 ft. (91 m) @ 1 Mbps
Security Encryption Types - WEP, TKIP, AES***
WPA 1.0 compliant
Encryption Key lengths Supported: 64 bits and 128 bits
802.1x/EAP
Maximum recommended number of computers
to be connected over wireless LAN (during ad hoc
connection)
10 units or less ****
fennec3.book Page 91 Wednesday, May 23, 2007 3:43 PM
