Fujitsu Lifebook AH530 User Manual

91 - Restoring Your System Image and Software
Recovering Your Factory Image
In the event you need to restore your original Factory Image, perform the following steps. Note that there
may be some third-party applications that need to be installed from the application media bundled with
your system.
In order to recover your Factory Image, perform the steps outlined in “Running Recovery and Utility from
hard disk”.
Backing Up a System Image
User-Configured System Backups: On your desktop, there is a [MyRecovery] icon that
allows you to make backups of your current system image either to another location on your
hard drive or on removable media. A system image is the configuration of your C: drive at a
particular point of time. You may want to make system image backups occasionally in order
to have points to which you can return without having to go all the way back to the Factory
Image.
By default, system images are saved in the D: drive in the MyRecovery folder. You can also elect to save
the image to an external hard drive.
1 Click the [MyRecovery] icon on your desktop.
2 Click the [Backup] button on the MyRecovery screen.
3 On the next screen that appears, you can enter up to 200 characters of information about the backup file. This
information will help you to identify the image at a later date.
4 Click the [Next] button and the system will reboot.
5 After rebooting, the “Creating of the backup image” window appears, in which you can either click [Create the
image on D drive] or [Select the drive] if you want to save to an external hard disk drive.
ALL USER-CREATED DATA WILL BE DELETED FROM YOUR SYSTEM WHEN THE FACTORY IMAGE IS
RESTORED.
My Recovery

Fujitsu Lifebook AH530 Specifications

General

Bus type	DMI
Stepping	K0
Tjunction	90 °C
Processor cache	3 MB
Processor cores	2
Processor model	i3-370M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-300 Mobile Series
Processor socket	Socket 988
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM55 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	Memory Stick (MS), MS PRO, SD, SDHC
Number of HDDs installed	1
Display surface	Gloss
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 2 GB
Maximum resolution	1920 x 1200 pixels
Discrete graphics card model	Intel HD
Maximum graphics card memory	- GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	667 MHz
Type	PC
Power supply type	AC/DC
Power requirements	100-240V, 50/60Hz
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Audio system	HDA
Pointing device	Touchpad
Keyboard key pitch	19.8 mm
Keyboard keystroke	1.8 mm
Keyboard number of keys	106
Front camera resolution (numeric)	1.3 MP
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Home Premium
Certification	CE, R&TTE, RoHS, WiFi, EPEAT, GOST
Sustainability certificates	ENERGY STAR
Battery capacity	4400 mAh
Battery life (max)	6 h
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
Cable lock slot type	Kensington
Product color	Black
Operating relative humidity (H-H)	20 - 85 %
AC adapter power	80 W
AC adapter output current	4.22 A
AC adapter output voltage	19 V
Processor code	SLBUK
Processor ARK ID	49020
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1, SSE4.2

Weight and Dimensions

Depth	252 mm
Width	378 mm
Weight	2500 g
Height (rear)	38.4 mm
Height (front)	35.7 mm
