Fujitsu LifeBook S7110 User Manual

80
LifeBook S7100 Notebook
FEATURES
Integrated Pointing Device
■
Touchpad pointing device with scroll button
■
Optional Quick Point cursor control button
■
Optional fingerprint swipe sensor
Communications
Modem: Internal V.90 standard 56K fax/modem
(ITU V.90, 56K data, 14.4K fax)
Gigabit LAN: Internal wired 10Base-T/100Base-Tx/
1000Base-T/Tx Ethernet LAN
Wireless Devices:
■
Optional integrated Intel PRO/Wireless 3945ABG
Network Connections (802.11a/b/g*) with Antenna
On/Off switch
■
Optional Bluetooth device for wireless personal area
network communication
* Operates at 2.4 GHz and 5.0 GHz; communications range may
vary, depending upon environment.
LifeBook Security/Application Panel
The Application Launcher buttons on your LifeBook
notebook default to the following applications:
Theft Prevention Lock
Lock slot for use with security restraint systems.
DEVICE PORTS
On the LifeBook notebook:
■
PC Card slot for Type I or Type II card: PCMCIA
Standard 2.1 with CardBus support
■
ExpressCard slot for one ExpressCard 54/34
■
One 15-pin D-SUB connector for VGA external video
(see Display specifications)
■
Three USB 2.0 (Universal Serial Bus) connectors for
input/output devices
■
One IEEE 1394 (4-pin type) jack
■
One modular modem (RJ-11) connector
■
One LAN (RJ-45) connector
■
One stereo headphone/line-out jack.
■
One stereo microphone/line-in jack.
■
Embedded Smart Card Reader (requires optional
third-party application and holder)
■
S-Video Out jack
■
Wireless LAN antenna with pre-installed on/off switch
■
Optional Bluetooth module with antenna
On the Optional Port Replicator:
■
One 6-pin mini DIN PS/2 compatible connectors for
external keyboard or mouse
■
One 25-pin D-SUB connector for parallel input/
output devices; Bi-directional, output only or ECP
■
One 15-pin D-SUB connector for VGA external video
(see Display specifications)
■
One 9-pin D-SUB connector for RS-232C serial
input/output devices
■
Four USB 2.0 (Universal Serial Bus) connectors for
input/output devices
■
One LAN (RJ-45) connector
■
One DC In connector
■
One microphone In jack
■
One headphone jack
■
One Digital Video (DVI-D) 24-pin, female interface
■
One power/suspend/resume button
KEYBOARD
Built-in keyboard with all functions of 101 key PS/2
compatible keyboards.
■
Total number of keys: 84
■
Function keys: F1 through F12
■
Feature extension key: Fn
■
Two Windows keys: one Start key, one application key
■
Key pitch: 19 mm
■
Key stroke: 3 mm
■
Built-in Touchpad pointing device with left and right
buttons and scroll button.
■
Built-in Palm Rest
■
Optional Quick Point cursor control button
External Keyboard Support
USB or PS/2-compatible (PS/2 compatible with Port
Replicator only)
External Mouse Support
USB or PS/2-compatible (PS/2 compatible with Port
Replicator only)
POWER
Batteries
One 6-cell Lithium ion battery, rechargeable, 10.8V,
5200 mAh, 56.16 Wh
Optional Flexible Bay battery: 6-cell Lithium ion battery,
rechargeable, 10.8V, 3800 mAh, 41.0 Wh
AC Adapter
Autosensing 100-240V AC, supplying 19V DC, 4.22A,
80W to the LifeBook notebook, including an AC cable.
Power Management
Conforms to ACPI (Advanced Configuration and Power
Interface).
Table 7-1 Application Launcher Defaults
Button
Label
Button
Function
Default Application
1 Application A Notepad
2 Application B Calculator
3 Internet Internet Explorer
4 E-Mail Microsoft Outlook or
Outlook Express
S7110.book Page 80 Monday, March 20, 2006 1:56 PM

Fujitsu LifeBook S7110 Specifications

General

Bus type	FSB
Stepping	B2
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T7000 Series
Processor socket	Socket 479
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	2 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	667 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	34 W
Processor core voltage (AC)	1.0375 - 1.30 V
CPU multiplier (bus/core ratio)	12
Number of Processing Die Transistors	291 M
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD±RW
Total storage capacity	80 GB
Display diagonal	14.1 \
Display resolution	1024 x 768 pixels
Native aspect ratio	4:3
Type	PC
Internal modem	Yes
Wireless technology	802.11 a/g/n
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Discrete graphics card model	Intel® GMA 950
Discrete graphics card memory	0.224 GB
Audio system	RealTek ALC262
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet, WLAN
Operating system installed	Windows XP Professional
Battery capacity	5200 mAh
Number of battery cells	6
TV-out type	S-Video
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
CardBus PCMCIA slot type	Type II
Cable lock slot type	Kensington
Password protection type	BIOS
Certification	CE, CE!, GS, CB, RoHS, TBR21, Energy Star, WHQL, WiFi
AC adapter input voltage	120 - 230 V
Processor ARK ID	27255
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	248 mm
Width	307 mm
Height	34.5 mm
Weight	1800 g
