USB 2.0 Port
This convenient guide will lead you through the start-up
process and will also offer some valuable tips.
LEFT PANEL
BOTTOM PANEL
RIGHT PANEL BACK PANEL
Controls, Connectors,
and Access Points
What’s in the Box
Check to see that all of the following items are in the box:
o LIFEBOOK notebook o Weight saver module
o Lithium ion battery, pre-installed o International Limited Warranty
o AC adapter with power cord and Registration Booklet
Depending upon your configuration, the following items may also be shipped with your notebook:
o Dual-Layer Multi-Format DVD and/or o Additional Lithium ion battery
CD-RW application disc o Modular Bay Battery
o Microsoft
®
associated material
Keyboard
Scroll Wheel
Power/Suspend/Resume
Button
Status Indicator Panel
Wireless Device On/Off Switch
Status Indicator Panel
SD Card Slot
Headphone Jack
Touchpad Pointing Device
Display Panel
Stereo Microphone
Stereo Microphone
Web Camera
Web Camera Indicator
USB 2.0 Port with Anytime USB Charge
DC Power Jack
Air Vents
HDMI Port
USB 3.0 Port Microphone Jack
Fingerprint Sensor
LIFEBOOK Security/Application
Panel
Stereo Speaker
Stereo Speaker
Air Vents (multiple
locations)
Battery
Release
Latch
Battery
Release
Latch
Port Replicator
Connector
Lithium ion Battery Pack
Dust Filter Cover
Flexible Bay
Device Lock
Memory Upgrade
Compartment
Express/PC Card
Eject Button
Air Vents
Security Lock Slot
LAN (RJ-45) Jack
Express/PC Card Slot Optical Drive Release Button External Video Port
Flexible Bay (shown with Optical Drive installed)
2
To Next Page
