Wall Mounted High-SEER 9, 12 and 15,000 BTU Systems
SYSTEMS 9RLS2, 12RLS2, 15RLS2
Note: Figures are based on 230 Volts. *Height when front panel is open.
Standard Features for RLS2 and RLS2H Models
Optional Accessories
Wireless Remote Control
Apple Catechin Filter
Ion Deodorizing Filter
Sleep Timer
24 Hour Timer
Weekly Timer
Dry Mode
Auto Louver: Up/Down
Auto Mode
Powerful Operation Mode
Minimum Heat
(50°F/10°C)
Wired Remote Controller: UTY-RVNUM
Backlit and includes room temperature
Wired Remote Controller: UTY-RNNUM
Simple Remote Controller: UTY-RSNUM
Communication Kit: UTY-TWBXF
These Halcyon systems know how to
save you money even when you forget. If you leave the
room without turning the
unit off, ESP knows that
you left and 20
minutes later,
set temperature
is increased by
4°F when cooling and
reduced by 8°F when
heating. When you come back to the room, it returns
to previous operating mode. This prevents wasteful
operation to save energy without you having to think
about it. This feature can be deactivated if chosen.
Energy Saving Program
High Performance Heating
Heating capacity at low outdoor temperatures was
improved by adopting a large heat exchanger and
a high capacity compressor. Rated heating capacity
is maintained up to 20°F. This new model can operate
down to -5°F.
SINGLE ZONE MINI-SPLITS
Up to 27.2 SEER
9RLS2
Heat Pump
12RLS2
Heat Pump
9,000 12,000
3,100~12,000
12,000
3,100~13,600
16,000
3,100~22,000
12.5
3,100~22,100
12.0
27.2 25.0
16.1/15.0 13.8/13.3
14~115 (-10~46)
-5~75 (-21~24)
2.75 (1.3)
14~115 (-10~46)
-5~75 (-21~24)
3.8 (1.8)
208-230/60/1 208-230/60/1
20 20
500 (850) 500 (850)
394 (670) 394 (670)
324 (550) 324 (550)
194 (330) 194 (330)
43/43 43/43
37/38 37/38
32/32 32/32
21/21 21/21
780/780 870/780
48/49 49/50
2.7 4.0
3.7 5.5
.56 .87
.80 1.20
4+Auto 4+Auto
Manual Manual
Auto Auto
Washable Washable
Yes Yes
Flare Flare
9 (2.7)
66 (20)
(pre-charge: 49’)
9 (2.7)
66 (20)
(pre-charge: 49’)
49 (15) 49 (15)
Suc. 3/8 Dis. 1/4 Suc. 3/8 Dis. 1/4
21 (9.5) 88 (40) 21 (9.5) 88 (40)
11-1/8
13-1/4*
24-13/32
11-1/8
13-1/4*
24-13/32
282/337*
620
282/337*
620
34-1/4
31-3/32
34-1/4
31-3/32
870 790 870 790
7-1/4
11-13/32
7-1/4
11-13/32
185
290
185
290
R410A R410A
Indoor
ASU9RLS2
Outdoor
AOU9RLS2
Indoor
ASU12RLS2
Outdoor
AOU12RLS2
15RLS2
Heat Pump
14,500
3,100~18,400
18,000
3,100~23,900
12.0
21.5
12.0/13.3
14~115 (-10~46)
-5~75 (-21~24)
4.44 (2.1)
208-230/60/1
20
530 (900)
436 (740)
336 (570)
229 (390)
45/45
40/40
33/34
25/27
870/780
51/51
5.5
6.1
1.21
1.35
4+Auto
Manual
Auto
Washable
Yes
Flare
9 (2.7)
66 (20)
(pre-charge: 49’)
49 (15)
Suc. 1/2 Dis. 1/4
21 (9.5) 88 (40)
11-1/8
13-1/4*
24-13/32
282/337*
620
34-1/4
31-3/32
870 790
7-1/4
11-13/32
185
290
R410A
Indoor
ASU15RLS2
Outdoor
AOU15RLS2
Nominal Cooling BTU/h
Min.~Max. Cooling BTU/h
Nominal Heating BTU/h
Min.~Max. Heating BTU/h
HSPF BTU/hW
SEER BTU/hW
EER Clg/Htg
Clg. Operating Range °F(°C)
Htg. Operating Range °F(°C)
Moisture Removal
Pt./h(l/h)
Voltage/Frequency/Phase
Recommended Fuse Size
(A)
Air Circ. C.F.M. (m
3
/h): Hi
Medium
Low
Quiet
Noise Level
dB(A): Hi
Medium
Low
Quiet
Outdoor Fan Speed
RPM Clg/Htg
Outdoor Noise Level dB(A)
Current Rated (A): Cooling
Heating
Power Use
Rated (kw): Cooling
Heating
Fan Speeds Stage
Air Direction: Horizontal
Vertical
Air Filter
Apple Catechin Filter
Connection Method
Combined Min. Lgth
Ft (m)
Combined Max. Lgth Ft (m)
Max. Vertical Diff. Ft (m)
Conn. Pipe Diameter Inch
Net Weight lbs. (kg)
Dimensions: Height Inch
mm
Width Inch
mm
Depth Inch
mm
Refrigerant
Economy Mode
Energy Saving Program
Quiet Mode
(Indoor)
Low Noise Mode
Auto Restart/Reset
Auto Changeover
Low Ambient Cooling
Cold Prevention
Remote Temp. Sensor
*
3
rd
Party Device Control
+
Systems 9RLS2, 12RLS2
* Available only with optional wired remote controller and optional interface kit.
+ Available only with optional interface kit. Operation monitoring and On/Off control only.
$
Federal Tax Credit Qualified
See Page 9 for details
Systems 9RLS2 and 12RLS2 only.
