44
ACCESSORIES
Wall Mounts
Wired Remote
Controller
*
UTY-RNBYU
^
/UTY-RNNUM
^
The wired remote controller with its unique
lock function and sleek design provides full
feature access to property managers,
building owners, and facility maintenance,
as well as providing basic comfort features
to tenants, employees, and teachers.
^ Minimum Heat, Sleep Timer functions will be lost when the wired remote controller is installed.
* Wall mounted ASU7, 9, and 12RLF require accessory interface kit (Part UTY-XCBXZ1) in order to connect this device to them. Wall mounted ASU9, 12,
and 15RLS2 require accessory interface kit (Part UTY-TWBXF) in order to connect this device to them.
** Internal thermosensor function in Wired Remote UTY-RNNUM is disabled when using this interface kit.
Wired Remote
Controller
UTY-RVNUM
Features a large backlit LCD display and
displays the room temperature. Provides
full feature access to property managers,
building owners, and facility maintenance,
as well as providing basic comfort features
to tenants, employees, and teachers.
Simple Remote
Controller
UTY-RSNUM*
Suitable when only basic operations
are required for hotels, offices and
other places where there is frequent
arrival and departure of occupants.
Remote does not allow any timer
settings.
Dry Contact
Wire Kit
*
UTY-XWZX/UTY-XWZXZ5
Turns system on or off using a normally
open circuit. For example in home
automation, BMS integration of only On/Off
operation, occupancy sensor, key card
switch, or lead-lag control of other
heating/cooling devices.
Required to connect the ASU9RLS2,
ASU12RLS2 and ASU15RLS2 to Wired
Remote UTY-RNNUM, Dry Contact Wire
Kit UTY-XWZXZ5, and Simple Remote
Control UTY-RSNUM.
Interface Kit
UTY-XCBXZ1**
Required to connect ASU7RLF, 9RLF,
12RLF and ASU15RLS to Wired Remote
UTY-RNNUM, Dry Contact Wire Kit
UTY-XWZX, and Simple Remote
Control UTY-RSNUM.
Interface Kit
UTY-TWBXF**
Universal Mount/Ceiling Susp. Ceiling Suspended Large Cassettes
Condensate Pump
UTR-DPB24T
OEM design plugs into factory harness
for ease of installation. Rated for 11.8”
of vertical lift. Only used with System
36RSLX.
Kit contains current sensor with built-in relay
(Split Core Fixed Threshold Current Status
Sensor with Command Relay) and Switching
Power Supply. Duct and Fan are field supply.
A fan capable of generating 15 CFM at a
static pressure of approximately .26 inches
W.C. required.
Wired Remote
Controller
UTY-RNBYU
**
The wired remote controller with its unique
lock function and sleek design provides full
feature access to property managers,
building owners, and facility maintenance,
as well as providing basic comfort features
to tenants, employees, and teachers.
Wireless Remote
Controller
UTY-LNHUM
For spaces where there is just no place to
mount the wired remote or where wireless
operation is preferred.
Fresh Air
Intake Kit
UTZ-VXAA
Mixes room air then passes it through a
heat exchanger. Allows for a 4-inch flex
duct connection. Requires a field supplied
duct booster fan capable of 60 CFM at
.2”W.C. or 90 CFM at .4”W.C. For fan
static pressure requirements, see
installation manual.
High Humidity
Insulation Kit
UTZ-KXGC
Additional insulation for compact cassette
units, which may be needed when they
are installed in high humidity areas.
Air Outlet
Shutter Plate
UTR-YDZB
In a 3-way air flow configuration an Air
Outlet Shutter Plate kit is required to block
air flow of 1 louver.
Compact Cassettes
Simple Remote
Controller
UTY-RSNUM
Suitable when only basic operations are
required for hotels, offices and other places
where there is frequent arrival and departure
of occupants. Timer feature is not available.
Dry Contact
Wire Kit
UTY-XWZX
Turns system on or off using a normally
open circuit. For example in home
automation, BMS integration of only On/Off
operation, occupancy sensor, key card
switch, or lead-lag control of other
heating/cooling devices.
Fresh Air Intake Kit
KHRS940-25
