Fujitsu Mini-Split User Manual

25
9RLFCD
Heat Pump
12RLFCD
Heat Pump
18RLFCD
Heat Pump
9,000 12,000 18,000
3,100~12,000 3,100~13,600 3,100~20,100
12,000 16,000 21,600
3,100~18,000 3,100~19,400 3,100~25,600
12.2 11.5 11.3
21.5 20.0 19.7
14.5/14.1 12.8/12.3 12.0/12.9
14~115 (-10~46) 14~115 (-10~46) 14~115 (-10~46)
-5~75 (-21~24) -5~75 (-21~24) -5~75 (-21~24)
1.5 (.07) 2.7 (1.3) 4.2 (2.0)
208-230/60/1 208-230/60/1 208-230/60/1
15 15 20
0 ~ 0.36 0 ~ 0.36 0 ~ 0.36
353 (600) 383 (650) 554 (940)
324 (550) 353 (600) 518 (880)
294 (500) 324 (550) 483 (820)
265 (450) 283 (480) 442 (750)
28/28 29/29 32/32
27/26 28/28 30/30
26/25 27/27 29/29
25/24 26/24 27/27
590/720 870/780 870/1,000
48/49 49/50 54/55
3.0/3.9 4.4/6.0 6.6/7.3
0.62/1.40 0.94/1.45 1.50/2.15
0.85/1.80 1.30/2.00 1.67/2.60
4 + Auto 4 + Auto 4 + Auto
Washable Washable Washable
Flare Flare Flare
9 (2.7) 9 (2.7) 9 (2.7)
66 (20)
(pre-charge: 49’)
66 (20)
(pre-charge: 49’)
66 (20)
(pre-charge: 49’)
49 (15) 49 (15) 49 (15)
suc 3/8 dis 1/4 suc 3/8 dis 1/4 suc 1/2 dis 1/4
41 (19) 41 (19) 50 (23)
84 (38) 84 (38) 86 (39)
7-25/32 (198) 7-25/32 (198) 7-25/32 (198)
27-9/16 (700) 27-9/16 (700) 35-7/16 (900)
24-13/32 (620) 24-13/32 (620) 24-13/32 (620)
5-15/16 (151) 5-15/16 (151) 5-15/16 (151)
25-19/32 (650) 25-19/32 (650) 33-15/32 (850)
3/4 (19) 3/4 (19) 3/4 (19)
6-27/32 (174) 6-27/32 (174) 6-27/32 (174)
22-19/32 (574) 22-19/32 (574) 30-15/32 (774)
3/4 (19) (Flat) 3/4 (19) (Flat) 3/4 (19) (Flat)
24-1/2 (620) 24-1/2 (620) 24-1/2 (620)
31-3/32 (790) 31-3/32 (790) 31-3/32 (790)
11-11/32 (290) 11-11/32 (290) 11-11/32 (290)
R410A R410A R410A
Nominal Cooling BTU/h
Min~Max Cooling BTU/h
Nominal Heating BTU/h
Min~Max Heating BTU/h
HSPF
SEER
EER
Clg/Htg
Cooling Operating Range °F(°C)
Heating Operating Range °F(°C)
Moisture Removal
Pt./h(l/h)
Voltage/Frequency/Phase
Recommended Fuse Size
(A)
Static Pressure In. W. C.
Air Circ. C.F.M. (m
3
/h) Clg/Htg: Hi
Medium
Low
Quiet
Noise Level
dB(A) (Clg/Htg): Hi
Medium
Low
Quiet
Outdoor Fan Speed
RPM Clg/Htg
Outdoor Noise Level Clg/Htg
Running Current Rated (A)Clg/Htg
Power Use Rated/Max (kW): Cooling
Heating
Fan Speeds Stage
Air Filter
Connection Method
Combined Min. Length
Ft (m)
Combined Max. Length Ft (m)
Max. Vertical Diff. Ft (m)
Conn. Pipe Diameter Inch
Indoor Unit Net Weight lbs. (kg)
Outdoor Unit Net Weight lbs. (kg)
Indoor Unit Dimensions: Height Inch (mm)
Width Inch (mm)
Depth Inch (mm)
Supply Duct Flange
Dimensions: Height Inch (mm)
Width Inch (mm)
Depth Inch (mm)
Return Duct Flange
Dimensions: Height Inch (mm)
Width Inch (mm)
Depth Inch (mm)
Outdoor Unit Dimensions: Height Inch (mm)
Width Inch (mm)
Depth Inch (mm)
Refrigerant
*Internal drain pump will not operate
when the unit is mounted in a vertical
configuration.
Return Air-intake Choices
Back
Bottom
Flexible Installation
Horizontal or vertical.
Compact Duct
Built-in drain pump allows for
installation of compact duct
unit in smaller spaces than
traditional units.
Drain
Pump
13”
9.4”
Traditional
Compact Duct
Note: Figures are based on 230 Volts.
Systems 9RLFCD, 12RLFCD
