Fujitsu provides knock-outs on all
ceiling cassettes where contractors
can:
• Install optional field supplied branch
ducts on up to two sides to supply up
to 18% capacity per side to adjoining
spaces up to 16 feet away.
See Design
and Technical Manual for details.
• Allows fresh air to be brought into the
indoor unit using fresh air knockout.
Note: Figures are based on 230 Volts.
Indoor
AUU36RCLX
Outdoor
AOU36RLX
Indoor
AUU42RCLX
Outdoor
AOU42RLX
Indoor
AUU18RCLX
Outdoor
AOU18RLX
Indoor
AUU24RCLX
Outdoor
AOU24RLX
18RCLX
Heat Pump
24RCLX
Heat Pump
36RCLX
Heat Pump
42RCLX
Heat Pump
17,800 22,200 34,100 42,700
5,000~21,500
21,000
5,000~27,300
24,200
8,500~36,000
36,000
13,700~45,000
45,200
11,300
5,000~25,600
8.5
14,600
5,000~29,000
8.5
23,000
9,200~42,700
8.5
28,200
14,300~54,600
8.5
16.0 15.0 14.0 15.0
11.1 / 10.2 10.6 / 10.2 8.1 / 9.7 9.2 / 10.5
0~115 (-18~46)
14~75 (-10~24)
5.3 (2.5)
0~115 (-18~46)
14~75 (-10~24)
6.4 (3.0)
0~115 (-18~46)
14~75 (-10~24)
8.5 (4.0)
0~115 (-18~46)
0~75 (-18~24)
11.6 (5.5)
208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1
20 20 30 30
559 (950) 618 (1,050) 942 (1,600) 1,000 (1,700)
477 (810) 536 (910) 824 (1,400) 854 (1,450)
394 (670) 436 (740) 677 (1,150) 736 (1,250)
42/40 (Clg/Htg) 45/43 (Clg/Htg) 48/48 (Clg/Htg) 50/50 (Clg/Htg)
39/38 (Clg/Htg) 43/39 (Clg/Htg) 45/45 (Clg/Htg) 48/48 (Clg/Htg)
36/36 (Clg/Htg) 38/35 (Clg/Htg) 41/41 (Clg/Htg) 44/44 (Clg/Htg)
780/780 850/900 850/900 850/750
51/53 (Clg/Htg) 53/55 (Clg/Htg) 54/55 (Clg/Htg) 55/56 (Clg/Htg)
7.0/12.5 9.2/12.5 18.3/18.8 20.3/21.7
8.9/12.5 10.4/12.5 16.1/18.8 18.8/21.7
1.61/2.88 2.10/2.88 4.22/4.35 4.66/4.99
2.05/2.88 2.37/2.88 3.70/4.35 4.31/4.99
3 + Auto 3 + Auto 3 + Auto 3 + Auto
- - - -
Automatic Automatic Automatic Automatic
Washable Washable Washable Washable
Removable Removable Removable Removable
Flare Flare Flare Flare
16 (5)
165 (50) Each
(pre-charge: 49’)
16 (5)
165 (50) Each
(pre-charge: 49’)
16 (5)
165 (50) Each
(pre-charge: 49’)
16 (5)
165 (50) Each
(pre-charge: 66)
65 (20) 65 (20) 98 (30) 98 (30)
Suc. 1/2 Dis. 1/4 Suc. 5/8 Dis. 3/8 Suc. 5/8 Dis. 3/8 Suc. 5/8 Dis. 3/8
75 (34) 141 (64) 75 (34) 141 (64) 82 (37) 141 (64) 88 (40) 231 (105)
9-3/4 32-3/4 9-3/4 32-3/4 11-5/8 32-3/4 11-5/8 50-7/8
246 830 246 830 296 830 296 1290
32-3/4 35-1/2 32-3/4 35-1/2 32-3/4 35-1/2 32-3/4 35-1/2
830 900 830 900 830 900 830 900
32-3/4 13 32-3/4 13 32-3/4 13 32-3/4 13
830 330 830 330 830 330 830 330
R410A R410A R410A R410A
Nominal Cooling BTU/h
Min.~Max. Cooling BTU/h
Nominal Heating BTU/h
Low Temp. Heating 17°F BTU/h
Min.~Max. Heating BTU/h
HSPF BTU/hW
SEER BTU/hW
EER Clg/Htg
Clg. Operating Range °F(°C)
Htg. Operating Range °F(°C)
Moisture Removal
Pt./h(l/h)
Voltage/Frequency/Phase
Recommended Fuse Size
(A)
Air Circ. C.F.M. (m
3
/h): Hi
Medium
Low
Noise Level
dB(A): Hi
Medium
Low
Outdoor Fan Speed
RPM
Outdoor Noise Level dB(A)
Current Rated/Max (A): Cooling
Heating
Power Use
Rated/Max (kw): Clg
Heating
Fan Speeds Stage
Air Direction: Horizontal
Vertical
Air Filter
Front Grille
Connection Method
Combined Min. Lgth
Ft (m)
Combined Max. Lgth Ft (m)
Max. Vertical Diff. Ft (m)
Conn. Pipe Diameter Inch
Net Weight lbs. (kg)
Dimensions: Height Inch
mm
Width Inch
mm
Depth Inch
mm
Refrigerant

Fujitsu Mini-Split Specifications
