35
AUU9RLF
Heat Pump
AUU12RLF
Heat Pump
AUU18RLF
Heat Pump
9,000 12,000 18,000
10,200 13,500 20,000
208-230/60/1 208-230/60/1 208-230/60/1
318 (540)
Clg or Htg
359 (610)
Clg or Htg
441 (750) Clg
471 (800) Htg
288 (490)
Clg or Htg
312 (530)
Clg or Htg
359 (610) Clg
418 (710) Htg
259 (440)
Clg or Htg
277 (470)
Clg or Htg
306 (520) Clg
353 (600) Htg
230 (390)
Clg or Htg
241 (410)
Clg or Htg
241 (410) Clg
265 (450) Htg
33/34 37/37 42/44
31/32 33/33 37/40
29/29 31/31 33/37
27/27 28/28 29/30
0.15 0.19 0.30
0.15 0.19 0.30
18 23 39
18 23 39
4+auto 4+auto 4+auto
Automatic Automatic Automatic
Washable Washable Washable
UTG-CCGF* UTG-CCGF* UTG-CCGF*
Flare Flare Flare
suc 3/8 dis 1/4 suc 3/8 dis 1/4 suc 1/2 dis 1/4
33 (15) 33 (15) 33 (15)
9-11/16 (245) 9-11/16 (245) 9-11/16 (245)
22-7/16 (570) 22-7/16 (570) 22-7/16 (570)
22-7/16 (570) 22-7/16 (570) 22-7/16 (570)
1-15/16 (49) 1-15/16 (49) 1-15/16 (49)
27-9/16 (700) 27-9/16 (700) 27-9/16 (700)
27-9/16 (700) 27-9/16 (700) 27-9/16 (700)
R410A R410A R410A
22.5”
22.5”
Easy Installation
Fits into a standard ceiling tile*.
*Dimensions of outer grille are 27-9/16” x 27-9/16”
and may overlap adjacent tiles.
Standard Features
Wired Remote Control
Sleep Timer
Dry Mode
Auto Louver: Up/ Down
Quiet Mode
Auto Restart/Reset
Remote Temperature Sensor
High Ceiling Mode
Condensate Pump
2-Stage Turbo Fan
Minimum Heat Mode+
Fresh Air Intake**
Nominal Cooling BTU/h
Nominal Heating BTU/h
Voltage/Frequency/Phase
Air Circ.
C.F.M. (m
3
/h): Hi
Medium
Low
Quiet
Noise Level
dB(A) Clg/Htg: Hi
Medium
Low
Quiet
Running Current
Rated (A): Cooling
Heating
Power Use
Rated/Max (W): Clg
Heating
Fan Speeds Stage
Air Direction: Vertical
Air Filter
Front Grille
Connection Method
Conn. Pipe Diameter
Inch
Net Weight lbs. (kg)
Chassis Dim: Height Inch (mm)
Width Inch (mm)
Depth Inch (mm)
Grille Dim: Height Inch (mm)
Width Inch (mm)
Depth Inch (mm)
Refrigerant
Fresh Air Kit**
UTZ-VXAA
Mixes room air then passes
through the heat exchanger.
2-Stage Turbo Fan
Air distribution is evenly spread across
the heat exchanger by the new 2 stage
turbo fan which produces two separate
airflow streams.
Heat exchange
efficiency:
Increased 20%
1-stage
2-stage
+ Available only with optional wireless remote control.
**Requires Fujitsu’s Optional Fresh Air Kit part #UTZ-VXAA. Allows for a 4-inch flex duct connection.
Requires a field supplied duct booster fan capable of 60 CFM at .2”W.C. or 90 CFM at .4”W.C.
For fan static pressure requirements, see installation manual. Add hood, filter and duct losses for
fan total static pressure requirements. Will add 4” to the height of the indoor unit.
* Compact Cassette Grille UTG-CCGF sold separately. Must order one with each compact cassette.
multi
18, 24, 36,000 BTUs
flex
48,000 BTUs
Compact Cassettes 9, 12, and 18,000 BTUs
AUU9RLF, AUU12RLF, AUU18RLF
