Modular RAID Controllers
Modular RAID 3Gb/s (SAS1.0)
Figure 6: Position of the cable connector LSliBBU01
Figure 7: Position of the cable connector LSIiBBU07
Note the cable connector marked with the red arrow and the holes (1) for the
screws that attach the LSliBBU01/LSliBBU07 to the chassis.
Cable connector
Bottom
1
1
1
1
1
1
J2
J5
J4
Cable connector
Bottom
1
1
1
