Fujitsu PRIMERGY CX2550 M1 - Starting Up and Operation; Controls and Indicators

CX2550 M1 Operating Manual 39
6 Starting up and operation
V CAUTION!
Please note the safety instructions in chapter "Important information" on
page 21.
6.1 Controls and indicators
6.1.1 Controls and indicators on the server node
Figure 3: Controls and indicators of the server node
I The server nodes are controlled via related operating panel areas on the
front side of the CX400 M1 server enclosure. See "FUJITSU Server
PRIMERGY CX400 M1 Server Enclosure Operating Manual".
1
RST button 3 ID indicator
2 Global error indicator 4 CSS inidicator
