Fujitsu PRIMERGY RX2530 M1

68 Operating Manual RX2530 M1
Starting up and operation
I Depending on the settings in the BIOS, the standard LAN connector 1
may also be used as a service LAN connector. You will find further
information in the "D3279 BIOS Setup Utility for PRIMERGY RX2530 M1
Reference Manual".
3LAN
link/transfer
(Management
LAN)
Lights up green when a LAN connection exists.
Remains dark when no LAN connection exists.
Flashes green when LAN transfer takes place.
4 LAN speed
(Management
LAN)
Lights up yellow in the event of a LAN transfer rate of
1 Gbit/s
Lights up green in the event of a LAN transfer rate of
100 Mbit/s.
Remains dark in the event of a LAN transfer rate of
10 Mbit/s.
No Indicator Description
