RX2530 M4
Operating Manual 23
Interfaces
Onboard or integrated controllers
USB connectors USB 3.0 connectors: 4 (2x front, 2x rear)
USB connectors
(10 HDD variant)
USB 2.0 connectors: 1 (1x on front panel QRL)
USB 3.0 connectors: 2 (2x rear)
Graphics (15-pin) 1x VGA (rear)
1x front VGA as an option (not for 10 HDD variant)
Serial (9-pin) 1 x serial RS-232-C, usable for iRMC S5 or system or
shared
LAN / Ethernet OCP option:
–4x 1 Gb
– 2x 10 Gb
– 2x 10 Gb SFP+
– 4x 10 Gb SFP+
Management LAN
(RJ45)
1 x dedicated management LAN connector for iRMC S5
(10/100/1000 Mbit/s). Management LAN traffic can be
switched to shared onboard Gbit LAN port.
RAID controller Modular Host Bus Adapter with "Integrated RAID" (IR).
RAID levels 0 and 1 are supported for internal HDD
configurations.
SATA controller Intel
®
C620, 1 x SATA channel for ODD
LAN controller OCP based on Emulex XE100 series;
PXE-Boot via LAN from PXE server, iSCSI / FCoE boot
(also diskless).
Remote
Management
Controller
Integrated Remote Management Controller (iRMC S5),
256 MB DDR3-800 SRAM for video, IPMI 2.0
compatible
Trusted Platform
Module (TPM)
Infineon / separate module; TCG V1.2 or TCG 2.0
compliant (option)
