Fujitsu PRIMERGY RX2530 M4 User Manual

RX2530 M4 Operating Manual
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Concept and target groups for this manual . . . . . . . . . . 9
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 10
1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 11
2 Functional overview . . . . . . . . . . . . . . . . . . . . . . 13
2.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.2 Server specification . . . . . . . . . . . . . . . . . . . . . . 22
3 Installation steps, overview . . . . . . . . . . . . . . . . . . 31
4 Important information . . . . . . . . . . . . . . . . . . . . . 33
4.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 33
4.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 42
4.4 Environmental protection . . . . . . . . . . . . . . . . . . . 43
5 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 45
5.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 46
5.2 Installing/removing the server in/from the rack . . . . . . . 47
5.3 Connecting devices to the server . . . . . . . . . . . . . . . 49
5.4 Connecting the liquid cooling (LC) to the external cooling
environment (special release) . . . . . . . . . . . . . . . . . 52
5.5 Connecting the server to the mains . . . . . . . . . . . . . . 53
5.5.1 Connecting the server to the direct current (optional DC PSU) . 54
5.5.2 Using the cable clamps (AC PSU) . . . . . . . . . . . . . . . . 56

Fujitsu PRIMERGY RX2530 M4 Specifications

General

Brand	Fujitsu
Model	PRIMERGY RX2530 M4
Category	Server
Language	English
