Fujitsu PRIMERGY RX2530 M4

RX2530 M4 Operating Manual 61
Starting up and operation
6.1.1.2 Indicators on the front panel
Figure 11: Indicators on the front panel module
Figure 12: Indicators on the front panel on QRL
Pos. Label Indicator Status Description
1 ID
ID
indicator,
see also
"iRMC-
related
status
signals" on
page 63
blue on
The server has been highlighted
using ServerView Operations
Manager, iRMC web interface or
the ID button on the front panel for
easy identification.
blue
flashing
The server has been highlighted
for easy identification using the
iRMC (AVR) with disabled local
VGA output.
