Fujitsu PRIMERGY RX2530 M4

RX2530 M4 Operating Manual 27
Functional overview
Electrical values of the AC PSU
Electrical values of the DC PSU -48 V
Electrical values of the HVDC PSU 380 V
Rated voltage range 100 V - 240 V (Platinum)
200 V - 240 V (Titanium)
Frequency 50 Hz - 60 Hz
Rated current with min. configuration 4.5 A / 2.0 A
Max. rated current 10.5 A / 5.0 A
Effective power 883 W
Apparent power 892 VA
Heat dissipation 3179 KJ/h (3013 BTU/h)
Main power fuse 16 A
Protection class I
Rated voltage -40.5 V - -57 V
Frequency DC
Max. rated current 20 A
Effective power 800 W
Main power fuse 16 A
Rated voltage 200 V - 380 V
Frequency DC
Max. rated current 5.5 A - 3.0 A
Effective power 1300 W
Main power fuse 16 A
