Fujitsu PRIMERGY RX300 S7 - Page 24

System configurator and order-information guide
PRIMERGY RX300 S7 Status 2013-12-30
SAS-/SCSI-/ Fibre-Channel Controller Low Profile
SAS controller for external backup drives
Only a single vendor for FC and
All controllers for the connection of external
FCoE controller is supported. storage system are delivered without cables.
For the configuration of external cabling see
the configurator for external storage system.
Fibre Channel Controller for external storage systems
S26361-F3631-E201 S26361-F3631-E202
loose delivery:
8GBit/s FC Controller
8GBit/s FC Controller
Single channel S26361-F3631-L201
Qlogic Qlogic Dual Channel S26361-F3631-L202
QLE2560, low profile bracket QLE2562, low profile bracket with mounted LP bracket
1 channel 8Gb/sec FC Controller
2 channel 8Gb/sec FC Controller
FH bracket is not included
LC Interface for 50µm Fiber LC Interface for 50µm Fiber
PCIe x8, 170mm
PCIe x8, 170mm
max. 6x per system max. 6x per system
6x
S26361-F3961-E201 S26361-F3961-E202 S26361-F4994-E201 S26361-F4994-E202
8GBit/s FC Controller
8GBit/s FC Controller
16GBit/s FC Controller 16GBit/s FC Controller
Emulex Emulex Emulex Emulex
LPe1250, low profile bracket LPe12002, low profile bracket LPe16000, low profile bracket LPe16002, low profile bracket
1 channel 8Gb/sec FC Controller
2 channel 8Gb/sec FC Controller
1 channel 16Gb/sec FC Contr.
2 channel 16Gb/sec FC Contr.
LC Interface for 50µm Fiber LC Interface for 50µm Fiber LC Interface for 50µm Fiber LC Interface for 50µm Fiber
PCIe x4, 170mm
PCIe x4, 170mm
PCIe x8, 170mm
PCIe x8, 170mm
max. 6x per system max. 6x per system max. 6x per system max. 6x per system
loose delivery: loose delivery:
Single channel S26361-F3961-L201 Single channel S26361-F4994-L501
Dual Channel S26361-F3961-L202 Dual Channel S26361-F4994-L502
with mounted LP bracket contains LP and FH brackets.
FH bracket is not included
M
L
max. 3x per system
S26361-F3628-E201
SAS Controller 6Gb/s 8 port LP
LSI SAS9200-8e LP
PCIe 2.0 x4,
ext: 8 port
Fujitsu PRIMERGY Server 24 of 31
