System configurator and order-information guide
PRIMERGY RX300 S7 Status 2013-12-30
Configuration diagram PRIMERGY RX300 S7
System unit ( I )
with up to 4, 8, 12 or 16x 2.5" Hard disk drives
Motherboard
front side
Memory CPU1
( Channel A + B + C )
Bay for LocalView LCD
Bank 1 (4 Modules)
Xeon DP
LSD
Bank 2 (4 Modules)
2 USB
Bank 3 (4 Modules)
Air channel VGA, LAN
Memory CPU2
Frontpanel
( Channel D + E + F)
Bay for 5,25"x 0,5" SATA-BR
Bank 1 (4 Modules)
Xeon DP
or DVD-ROM/RW
Bank 2 (4 Modules)
Bank 3 (4 Modules)
Accessible drives ( V )
Memory (III ) Processor ( II )
rear side Needs space for 4
Fan 1 - Fan 5 2.5" hard disk drives!
1. PSU
2. PSU
3.5"x1,6"
Redundant Fans
are standard!
Backup drive option 1
Redundant power
supply option
Needs space for 8
2.5" hard disk drives!
5.25"x1,6"
Modular RAID
Raid Card for IME, Raid 0 / 1E
Support Raid Card for Raid 5 Backup drive option 2
Low-profile extension slots for:
SCSI Controller for backup( VII )
Hard disk drives ( VI )
SAS Disk Array ( VIII ) 2.5" SAS/SATA
Communication/Network ( IX )
Miscellaneous ( X ) Up to 4 blocks with 4 HDDs
Slot 6 PCIe-3 x16, 390mm @ CPU2
Slot 5 PCIe-3 x16, 390mm @ CPU2
Slot 4 PCIe-3 x8, max. 390mm @ CPU1
Possibility to install PCIe x16 cards
Slot 3 PCIe-3 x8, max. 390mm @ CPU1
Slot 2 PCIe-3 x8, max. 312mm @ CPU1
Slot 1 PCIe-3 x8, max. 168mm @ CPU1 white colored
Dedicated for modular on-board LAN-Controller
Slot 7 PCIe-3 x8, max. 168mm @ CPU1
Internal slot for modular RAID-Controller
Key:
Included in basic unit Option
One CPU, one memory per CPU and one PSU has to be selected for an orderable basic unit.
2.5" SAS or SATA
2.5" SAS or SATA
2.5" SAS or SATA
2.5" SAS or SATA
2.5" SAS or SATA
2.5" SAS or SATA
2.5" SAS or SATA
2.5" SAS or SATA
