Fujitsu PRIMERGY TX100 S1 User Manual

42 Options Guide TX100 S1
Cabling Appendix
Figure 21: Power supply cabling
HDD1
PSU E548-V50
P9 ->
<- P8 <- P1
<- P12
<- P11
<- P14 <- P13
optical Drive
(top)
Floppy
(optional)
Optical drive
(top)
USB DAT/RDX drive
(bottom)
Front panel
USB front
<- P2 <- P3 <- P4
optical Drive
(top)
2nd optical drive
(bottom)
<- P5
only one of them
HDD2
Power SAS FDD
Data
Legend:
USB I
2
C
SATA
Parallel/serial Adapter
Intrusion
HDD3* HDD4*
*only available in configurations with 4 HDDs
