Fujitsu PRIMERGY TX100 S1 User Manual

TX100 S1 Options Guide 43
Appendix Cabling
Figure 22: Basic cabling with parallel interface option
Power SAS FDD
Data
Legend:
USB I
2
C
SATA
Parallel/serial Adapter
Intrusion
*only available in configurations with 4 HDDs
System
fan1
front
HDD1 HDD3* HDD2 HDD4*
optical Drive
(top)
Floppy
(optional)
Optical drive
(top)
USB drive
(bottom)
Front panel
USB front
T26139-Y3894-V513
T26139-Y1248-V8
T26139-Y3958-V202
T26139-Y3959-V105
T26139-Y3959-V105
T26139-Y3701-V147
T26139-Y3959-V105
T26139-Y3959-V105
System
fan2
rear*
A3C40082272
T26139-Y3910-V52 (optional)
Slot1
