Data Sheet FUJITSU Server PRIMERGY TX200 S7 Dual socket Intel® Xeon® processor tower server
Page 4 / 10 www.fujitsu.com/fts
Onboard or integrated Controller
SATA Controller Intel® C602, 6-port SATA (4x for internal hard disks, 2x for accessible drives)
SATA controller type notes On board SATA controller supports RAID levels 0, 1, 10
Remote Management Controller Integrated Remote Management Controller (iRMC S3, 32 MB attached memory incl. graphics controller)
IPMI 2.0 compatible
Trusted Platform Module (TPM) Inneon / separate module; TCG V1.2 compliant (option)
Slots
PCI-Express 3.0 x4 (mech. x8) 2 x Full height 280 mm length
PCI-Express 3.0 x16 2 x Full height rst slot: 280 mm length, second slot: 170 mm length (only available with second CPU)
PCI-Express 2.0 x4 (mech. x8) 1 x Full height 230 mm length; preferred RAID slot
PCI-slots 1 x PCI 32/33 MHz, 1x long, 5V
Slot Notes in SAS conguration 1x PCI-Express occupied by modular RAID controller
Drive bays
Storage drive bays 3.5-inch or 2.5-inch hot-plug SAS/SATA
Accessible drive bays 3 x 5.25/1.6-inch
Notes accessible drives All possible options described in relevant system congurator.
Storage drive bays Max 8 (4 + 4) x 3.5-inch Max 16 (8 + 8) x 2.5-inch
Accessible drive bays 3 x 5.25/1.6-inch for 4 x 3.5-inch HDD/SSD, or 2 x 3.5-inch
HDD/SSD + 1 x backup drive + local service display
1 x 5.25/0.5-inch for slimline ODD
3 x 5.25/1.6-inch for 8 x 2.5-inch HDD/SSD + backup drive/
ODD, or 8 x 2.5-inch HDD/SSD + slim ODD + local service
display
Fan Conguration
Number of fans 4
Fan conguration 3 + 1 redundant
Fan notes redundant fan conguration depends on base unit and is only available in combination with redundant PSU
Number of fans 3 4 3 4
Fan conguration 3 + 1 redundant 3 + 1 redundant
Fan notes non redundant / non hot-
plug
redundant / non hot-plug non redundant / non hot-
plug
redundant / non hot-plug
Operating panel
Operating buttons On/off switch
NMI button
Reset button
Status LEDs System status (orange / yellow)
Identication (blue)
Hard disks access (green)
Power (amber / green)
CPU status
Fan status
Hard disk error
Temperature
CSS (yellow)
Memory status
PSU status (green/ amber)
At system rear side:
System status (orange / yellow)
Identication (blue)
LAN connection (green)
LAN speed (green / yellow)
Service display Optional:
ServerView Local Service Display (LSD)
