Fujitsu PRIMERGY TX2540 M1

TX2540 M1 Operating Manual 75
Starting up and operation
LAN indicators
Figure 13: Indicators on the connection panel: LAN indicators
I Depending on the settings in the BIOS, the standard LAN port 1 may also
be used as a management LAN port. You will find further information in
the "D3099 BIOS Setup Utility for FUJITSU Server PRIMERGY
TX2540 M1 Reference Manual".
1LAN
link/transfer
indicator
Steady green signal when a LAN connection exists.
Remains dark when no LAN connection exists.
Flashes green when LAN transfer takes place.
2 LAN speed
indicator
Steady yellow signal in the event of a LAN transfer rate
of 1 Gbit/s
Steady green signal in the event of a LAN transfer rate
of 100 Mbit/s.
Remains dark in the event of a LAN transfer rate of
10 Mbit/s.
