06-07
Number of indoor unit connection
124
Setting by DIP SW 1-2
Remote controller PCB
Remote controller switch 1
If 2 sets of wired remote controllers are connected to the remote control group,
turn the DIP SW 1-1 of Master Remote Controller off.
Setting by DIP SW 1-1
Remote controller unit PCB
[Master] [Slave] [Master]
ONSW1-1 OFF
ON
ON OFF
ON
this switch must be set ON.
When only 1 remote controller will connect,
