Fujitsu ScanSnap S1300 Installation & Troubleshooting Guide

If you have installed the software before
22
6. Click the [ScanSnap] button.
Example: [Install Products] dialog box for S1500
 The [ScanSnap] dialog box appears, displaying the [Welcome to the InstallShield
Wizard for ScanSnap] screen. Follow the instructions on the screen to continue with
the installation.
If you did not perform the procedure in "Removing the installation information" and then failed to install
the software, perform the following procedures again:
- "Uninstalling the software" (page 12)
- "Removing the installation information" (page 16)
- "Installing the software from the [ScanSnap Setup] dialog box" (page 20)
If you still could not reinstall the software after performing the above procedures, proceed to "Installing
one software at a time" (page 23).

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
