Fujitsu ScanSnap S1300 Installation & Troubleshooting Guide

Installing in Windows
41
7. Confirm the check boxes of the software that you want to install are
selected, and click the [Next] button.
 The [Choose Destination Location] screen appears.
8. Confirm the destination folder, and then click the [Next] button.
 A confirmation about accepting the license agreement appears.
9. Read the "END-USER LICENSE AGREEMENT", select [I accept the
terms of the license agreement], and then click the [Next] button.
 The [Start Copying Files] screen appears.
10.Confirm the settings, and then click the [Next] button.
 Installation starts.
On S1500/S1500M/S1300, the "Install Complete" screen appears when the
installation is complete. Go to step 13.
On S1100, the [ScanSnap S1100 How to load a document (1/2)] screen appears
when the installation is complete. Go to step 11.
z The software will not be installed unless the check box is selected.
z Note that you must install ScanSnap Manager. Also, it is recommneded to install all software
in order to utilize the features of the ScanSnap.
Depending on the number of the installed software, this step may be required more than
once.

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
