Ports and controls
4 Fujitsu
P
orts and controls
This chapter presents the individual hardware components of your device. It gives you an overview
of the device’s indicators and connections. Please familiarize yourself with these components
before you start to work with the device.
Main Unit
Front
Rear
Notification button 1
Notification button 2
Charging terminal
Power button
Notification LED
Atmospheric
sensor hole
Sensor hole
