All kits must be connected in of the house as shown on
the gures (page 30, 31, 32 and 33).
"
DHW tank control (with electrical back-up) requires
the use of the DHW kit.
Warning : The DHW tank must be tted with an electric
back-up, particularly for anti-legionella cycles.
"
The connection of an oil or gas boiler to the heat pump
requires the installation of the boiler connection kit.
"
Please refer to the instructions supplied with the
swimming pool kit.
Conguration
(Parameter 5700)
Type of installation Page
Pre-setting 1 1 heating circuit. 30
Pre-setting 2 1 heating circuit and DHW tank. 31
Pre-setting 3
Do not use for monobloc heat pump. Reserved only for 2 circuits installation.
Pre-setting 4
Pre-setting 5 Boiler connection and 1 heating circuit. 32
Pre-setting 6 Do not use for monobloc heat pump. Reserved only for 2 circuits installation.
Pre-setting 7 Boiler connection, 1 heating circuit and DHW tank. 33
Pre-setting 8 Do not use for monobloc heat pump. Reserved only for 2 circuits installation.
Pre-setting 9
Do not use for monobloc heat pump. Reserved only for heat pump 2 services.
Pre-setting 10
Pre-setting 11
Pre-setting 12
"
Installation and operating manual "1395 - EN"
