Before switching on the control box :
• Check the electric wiring.
• Check the pressure of the hydraulic circuit (1-2 bar),
check that the heat pump is purged, and the rest of the
installation.
- Turn the start/stop switch.
- Congure the hydraulic circuit (setting 5700) :
Presettings :
1. 1 heating circuit (by default).
2. 1 heating circuit and DHW tank.
3. Boiler backup and 1 heating circuit.
4. Boiler backup, 1 heating circuit
and DHW tank.
- Time, Date and time programs for HC1, DHW if
different than default values (settings 500 – 576).
- Ajust the heating curve slope (720) and curve off-set (721).
You can also :
1. Adjust the heating circuit setpoints if different
than default values (710 – 714).
2. Adjust the DHW setpoints if different than
default values (1610-1612).
3. Start a legionella cycle (1640-1647).
4. Perform oor drying (850-857).
Heat pump. OK Non compliant
Location and ttings, condensate evacuation.
Compliance with distances from obstacles.
OK Non compliant Value
Connection of pipes, valves and pumps (1 circuit, DHW).
Installation water volume (expansion vessel of adequate capacity ?).
No leaks.
Main system pressure and degassing (0,3bar > expansion vessel pre-loading).
heat pump. OK Non compliant Value
Main power supply heat pump 230v .
Protection by rated circuit breaker.
Cable cross-section.
Earth connection.
Control box (see chapiter "Electrical connections" page 9). OK Non compliant
Connection with outdoor unit (3 + Eath).
Sensors connection (positioning and connections).
3 way valve and circulators connections.
Power supply and protection of electric auxiliary.
Installation and operating manual "1395 - EN"
Control Box
- 36 -
