Setting Description Set to. Menus

20 language operator section
1 hour / minutes time & date
2 day / month time & date
3 year time & date
5700 installation cong. conguration

710 comfort setpoint HC1 adjust.
712 reduced setpoint HC1 adjust.
720 heating curve slope HC1 adjust.
741 ow temp setpoint max HC1 adjust.
750 room inuence HC1 adjust.
790 / 791 optimis. at switch-on / off HC1 adjust.
834 servomotor travel time HC1 adjust.
850 / 851 oor drying HC1 adjust.
501 to 516 time programs HC1 program.
642 to 648 holiday programs HC1 hol pgm.

1610 nominal DHW temp. setpoint DHW
1612 reduced DWH temp. setpoint DHW
1620 DHW release DHW
1640 to 1647 legionella cycle DHW
1660 release DHW circulation DHW
5020 ow temp. increase DHW tank
5024 DHW switch-on differ. DHW tank
5030 charging time limitation DHW tank
5060 heater operation mode ll. DHW tank
5061 heater release DHW tank
5870 tank present (if DHW kit) conguration
561 to 576 time programs prog.4 DHW
Setting Description Set to. Menus

3700 OT.switch-on authoris. addit. gen.
3705 swith-off delay addit. gen.

6046 input H2 function 9 conguration
6100 OT sensor correction conguration
6120 frost protection on/off conguration
6205 reset settings conguration
6220 software version conguration
6711 reset heat pump error
7070 to 7183 maintenance maintenance
7700 to 7916 input / output testing I/O testing
8402 to 8457 generator diagnosis gen. diagn.
8700 to 9055 consumer diagnosis cons. diagn.

5711 cooling unit 2 pipes conguration
901 to 969 cooling settings cooling circuit 1

No. 10 outdoor sensor
No. 33 ow temp. sensor
No. 44 return temp. sensor
No. 50 DHW temp. sensor
No. 60 room sensor 1
No. 105 maintenance message
No. 121 HC1 ow T not reached
No. 127 leg. prot. T not reached
No. 369 external fault (EX6)
No. 370 outdoor unit connect error
6740 to 6746 alarm timeout error
6800 to 6818 last 10 alarms history error
6711 reset heat pump error

2844 switch-off temp max heat pump
2884 OT auth. to start elec. aux.
(not available)
heat pump
2920 Pk day clear (EX4) rel / lock heat pump

2056 generator setpoint Sw pool

Installation and operating manual "1395 - EN"
Control Box
- 38 -
