4. Method of remove the parts of Electrical Equipment
08
1: First remove the screw (2 pieces) and then remove
the cover of Electrical Equipment Box.
2: Inside of the Electrical Equipment Box.
3: Put outside of product.
1: Remove the screw (3 piece).
2: Pull the Damper Unit out to the direction of arrow.
Damper Unit
Screw
Electrical
Equipment
Box
Screw
Capacitor
Terminal
Relay
5. Method of remove the parts of Damper Unit
To Next Page
