Fujitsu WATERSTAGE UTW-SCB A Series User Manual

Line Function Setting range or display Setting
increment
Basic setting

If the installation is tted with a DHW tank. (Only with the DHW kit option).
560 Pre-selection (Day / Week)
Mon-Sun Mon-Fri Sat-Sun Monday Tuesday…

561 1
st
phase On (start) 00:00... --:-- 10 min 
562 1
st
phase Off (end) 00:00... --:-- 10 min 
563 2
nd
phase On (start) 00:00... --:-- 10 min 
564 2
nd
phase Off (end) 00:00... --:-- 10 min 
565 3
rd
phase On (start) 00:00... --:-- 10 min 
566 3
rd
phase Off (end) 00:00... --:-- 10 min 
576 Default values No, Yes 
Yes + OK : The default values memorised in the regulator replace and cancel the customised heating programmes.
Your customised settings are therefore lost.

600 Pre-selection (Day / Week)
Mon-Sun Mon-Fri Sat-Sun Monday Tuesday…

601 1
st
phase On (start) 00:00... --:-- 10 min 
602 1
st
phase Off (end) 00:00... --:-- 10 min 
603 2
nd
phase On (start) 00:00... --:-- 10 min 
604 2
nd
phase Off (end) 00:00... --:-- 10 min 
605 3
rd
phase On (start) 00:00... --:-- 10 min 
606 3
rd
phase Off (end) 00:00... --:-- 10 min 
616 Default values No, Yes 
Yes + OK : The default values memorised in the regulator replace and cancel the customised heating programmes.
Your customised settings are therefore lost.

641 Preselection Period 1 to 8 
642 Start (Day / Month) 01.01... 31.12 1
643 End (Day / Month) 01.01... 31.12 1
648 Operating level (during the holidays) Frost protection, Reduced 


710 Comfort heating setpoint from reduced setpoint to 35°C 0,5 °C 
712 Reduced setpoint from frost protection setpoint…
to comfort setpoint
0,5 °C 
714 Frost protection setpoint from 4°C…
to reduced setpoint
0,5 °C 

901 Operating mode Off, Automatic 
902 Comfort cooling setpoint 17... 40 °C 0,5 °C 
907 Release 24h/day, Time program HC,
Time program 5 / Cooling


If the installation is tted with a DHW tank, set the parameter 907 to " Time program 5 / Cooling"
(In order to activate cooling only during the day and leave the DHW system to operate during the night).
Operation manual "1408 - EN"
Control Box
- 10 -
