２２ .AIR PURGE VALVE removal
Remove the clip for the hose Remove the AIR PURGE VALVE
Remove the hose. by using 2 spanners.
２３ .SENSOR (TEMP.OUTDOOR) removal
Remove the SENSOR (TEMP.OUTDOOR) by hand.
２４ .SENSOR (TEMP.DISCHARGE) removal
Remove the SENSOR (TEMP.DISCHARGE) with the holder.
Hose band
Hose
2 spanners
Sensor
Sensor
Sensor and Holder
Holder
-31-
