１２ .FAN BRACKET and SEPARATE WALL removal
Remove the screws. (2 places)
Remove the FAN BRACKET.
Remove the screws. (3 places) Remov e the screws. (3 places)
Remove the SEPARATE WALL.
Screw
Earth
screw
Screw
-23-
