１１ .FAN MOTOR removal
Remove the fixing nut. Remove the cable for the FAN MOTOR.
Remove the PRPELLER FAN. from the hooks in the fan bracket. (3 places)
Note at the installation.
Tightening torque is from 4.0 to 6.0 N・m.
Note at the installation.
Remove the screws. (4 places)
Remove the FAN MOTER.
Nut
Cable for the FAN MOTOR
Cable for the SENSOR (TEMP.OUTDOOR)
Screw
Hook
-22-
