stops the red dot then increases the head's rotational speed in 4 steps up to a
maximum speed of 600rpm.
For Interior work we suggest using slower speeds, where the laser beam is
easier to see by eye; but for Exterior Groundworks – run the FRE-207 @ its
max. speed of 600rpm, which gives the best working range when used with
the supplied Laser Detector.
SCAN function - for Interior work:
The second button up on the right of the keypad is the Scan function. The
User can set a Dot, or 10, 45, 90, 180 degree lines as required & use the two
buttons above to move the "line" position around the room.
AS THIS LASER AUTO LEVELS BOTH HORIZONTALLY & VERTICALLY,
all the control settings above operate in either mode.
Grading:
This is a TRUE DUAL GRADE laser level. This means that the FRE-207 can
be switched to "manual" (to over-ride the level sensors) and then it is very
easy for the User to set a grade (incline/slope) in the X axis only, Y axis only
or both together. The max. settable slope range is +/- 10.00% ie. 1:10
For X & Y alignment, please see the white markings on the TOP of the laser
body where an arrow points in the direction of the axis being set.
Setting a single axis slope -
This sets a grade in the X axis.
Procedure – switch ON; the FRE-207 then auto levels. Press the red "G"
button on the Remote Control or laser's keypad & the X illuminates on the
screen. Using the top two right hand buttons, set the % value required.
The same buttons can be found on the Remote Control. Press the X/Y button
TWICE and the laser will adjust to this angle of slope, then rotate.
To return to Auto level, switch the laser OFF & ON again via the green button,
to reset the % values to zero. The Laser will wait to find true level, then
automatically restart, self levelled.
Setting Y axis slope -
This sets a grade in the Y axis.
3
