1. Remove the wooden block under the cylinder. ( See Figure 18a.)
2. Pull the wedge back. (See Figure 18b.)
Connect wedge and cylinder
Figure 17b
M8 x 16 × 2
4
2. Insert the bending plate into the U-shaped narrow slot of the slide-
rail, align the two holes on the bending plate with the two holes on
the slide-rail, and then tighten them with M8x16 bolts. (See Figure
17b.)
3. Assemble the wedge and cylinder. (See Figure 18c.)
Figure 17a
Figure 18a
Figure 18b
Figure 18c
1. Pull out the side spring pin and insert the slide-rail through the xed
guide rail until the two bolt holes on the slide-rail are fully exposed.
(See Figure 17a.)
Slide-rail Assembly
Fixed Guide Rail
1
2
Side Spring Pin
Slide-rail
Bolt Holes
1
2
M8x16(x2)
Bending Plate
Slide-rail
Fixed Guide Rail
1
2
Side Spring Pin
Slide-rail
Bolt Holes
1
2
M8x16(x2)
Bending Plate
Slide-rail
6 mm
8 mm
5 mm
10 mm
1
2
Block
Cylinder
5
Cylinder
Cylinder
3
4
Wedge
Cylinder
3
4
Wedge
21 mm
20 mm
21 mm
20 mm
22
Gas Log Splitter
»
Operator’s Manual
Assembly
|
