Full Boar H6038FB - Page 25

2. Pass the rotating shaft through the connecting plate, right support
leg, long bushing, left support leg, and short bushing in sequence,
and nally, wrap it outside the beam pivot pin, then x it on the
connecting plate with M8x20 bolts and washers. (See Figure 21b.)
1. Remove the long bushing and short bushing from the rotating shaft
before assembly. (See Figure 21a.)
Log Lift Table Attachment Assembly
Connecting Plate
Rotating Shaft
Short Bushing
Beam Pivot Pin
M8x20 (x1)
Rotating Shaft
Short Bushing
Long Bushing
7
1
2
3
4
5
6
7
M8 x 20 x 1
7
32 mm
13 mm
16 mm
19 mm
Figure 21b
Figure 21a
1. The front hole of the swing arm is xed to the short shaft on the
side of the left leg with bushing, washer and cotter pin. and the rear
hole of the swing arm is xed on the short shaft on the inside of the
bending plate. The inner side is xed with a bushing, a washer and a
cotter pin. (See Figure 22.)
Swing Arm Assembly
25 x 20 x 8 x 2
8
φ 20 x 2
5 x 35 x 2
Pin5 X 35 (x2)
Washer φ 20 (x2)
Bushing 25 X 20 X 8 (x2)
Swing Arm
Figure 22
Rotating
Shaft
Short
Bushing
Long
Bushing
24
Gas Log Splitter
»
Operator’s Manual
Assembly
|
