FUNAI DDVR-6830 - Page 56

1-15-2 H9903PIN
46 -
NUB Not Used
-
47 IN
LP LP
-
48 IN
FSC-IN
[4.43MHz]
4.43MHz Clock
Input
-
49 -
OSDVss OSDVss
-
50 IN
OSD-V-
IN
OSD Video Signal
Input
-
51 -
NU Not Used
-
52 OUT
OSD-V-
OUT
OSD Video Signal
Output
-
53 -
OSDVcc OSDVcc
-
54 -
HLF
LPF Connected
Terminal (Slicer)
-
55
AIN
COLOR-
IN
SECAM or
MESECAM
Chroma Video
Input Signal at
Super Impose
-
B-
NU Not Used
-
56 -
NU Not Used
-
57 -
NU Not Used
-
58 IN
C-SYNC
Composite
Synchronized
Pulse
PULSE
59 OUT
8POUT-1
Control SCART 1
8Pin Level by
using 8POUT-1
and 8POUT-2
H/L
60 OUT
8POUT-2
Control SCART 1
8Pin Level by
using 8POUT-1
and 8POUT-2
Hi-z/L
61 -
NU Not Used
-
62 -
NU Not Used
-
63 -
NU Not Used
-
64 -
NU Not Used
-
65 -
NU Not Used
-
66 OUT
C-POW-
SW
Capstan Power
Switching Signal
H/L
67 OUT
P-ON-H
Power On Signal
at High
H
68 OUT
DRV-
DATA
VFD Driver IC
Control Data
H/L
69 OUT
DRV-STB
VFD Driver IC
Chip Select
Signal
H/L
70 OUT
DRV-CLK
VFD Driver IC
Control Clock
H/L
71 OUT
IIC-BUS-
SCL
IIC BUS Control
Clock
H/L
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
72
IN/
OUT
IIC-BUS-
SDA
IIC BUS Control
Data
H/L
73 -
NU Not Used
-
74 -
NU Not Used
-
75 IN
DVD-
POWER-
MONITOR
DVD Power
Monitor Signal (P-
off=“L”, P-on=“H”)
H/L
76 OUT
C-CONT
Capstan Motor
Control Signal
PWM
77 OUT
D-CONT
Drum Motor
Control Signal
PWM
78 OUT
C-F/R
Capstan Motor
FWD/REV
Control Signal
(FWD=“L”/
REV=“H”)
H/L
79 IN
S-REEL
Supply Reel
Rotation Signal
PULSE
80 IN
T- R E EL
Take Up Reel
Rotation Signal
PULSE
81 OUT
LM-
FWD/
REV
Loading Motor
Control Signal
H/L/
Hi-z
82 OUT
OUTPUT-
SELECT
Output Select H/L
83 OUT
AUDIO-
MUTE-H
Audio Mute
Control Signal
(Mute = “H”)
H
84 -
NU Not Used
-
85 -
NU Not Used
-
86 IN
A-MODE
Hi-Fi Tape
Detection Signal
L
87 IN
C-FG
Capstan Motor
Rotation
Detection Pulse
PULSE
88 -
NU Not Used
-
89 -
NU Not Used
-
90
IN
D-PFG
Drum Motor
Phase/Frequency
Generator
PULSE
91 -
AMPVRE
F OUT
V-Ref for CTL
AMP
-
92 -
AMPVRE
F in
V-Ref for CTL
AMP
-
93 -
P80/C P80/C Terminal
-
94
IN/
OUT
CTL (-)
Playback/Record
Control Signal (-)
H/L
95
IN/
OUT
CTL (+)
Playback/Record
Control Signal (+)
H/L
96 -
AMPC
CTL AMP
Connected
Terminal
-
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
