Notes:
Abbreviation for Active Level:
PWM -----Pulse Wide Modulation
A/D--------Analog - Digital Converter
IC612 ( FIP DRIVER )
97 -
CTL
To Monitor for
CTL AMP Output
PULSE
98 -
AMPVcc AMPVcc
-
99 -
AVcc
A/D Converter
Power Input/
Standard Voltage
Input
-
100 IN
AGC
IF AGC
Comparator
Signal
A/D
Pin
No.
IN/
OUT
Signal
Name
Name Function
1 IN FP-CLK
Clock Input
2 IN FP-STB
Serial Interface Strobe
3 -
NU
Not Used
4 -
NU
Not Used
5 - VSS
GND
6 - VDD
Power Supply
7
OUT
a
Segment Output
8 b
9 c
10 d
11 e
12 f
13 g
14 h
15 - VEE
Pull Down Level
16 OUT i
Segment Output
17
OUT
7G
Grid Output
18 6G
19 5G
20 4G
21 3G
22 2G
23 1G
24 - VDD
Power Supply
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
25 - VSS
GND
26 IN OSC
Oscillator Input
27 -
NU
Not Used
28 IN FP-DIN
Serial Data Input
Pin
No.
IN/
OUT
Signal
Name
Name Function
